In the event that you are looking for void regions at lower cost and high features than hot culmination or hot formed round void fragment is by and large used for basic and mechanical applications and is fitting for your need. This hot design void section is less complex to contort when diverged from cold formed void regions. These vacant regions are used in arranging of twisted housings. These hot finished void regions things offer lighter, more grounded and extra astounding game plans got together with other redesigned sleek charm.
The size of these unfilled region lines and chambers changes from 21.3mm and 508 mm. The thickness lies from 2.5mm to 20mm in the greater regions. The available grades of these hot construction regions are S355J2H. There are various associations are advantage online which offers hot consummation indirect void regions at standard lengths or they can cut length according to your solicitation. These hot finished void regions are arranged primarily from fine grain steel for better execution. The thing has yield strength 355 N/mm2 and licenses higher assembling factors and has lighter plan and it is cost saving material to place assets into your any kind of basic and constructional projects.
Standard : BS EN 10210 - Hot Finished Structural Hollow Sections of Non-alloy and Fine Grain Steels
Available Grades : S235JRH, S275J0H, S275J2H, S355J0H, S355J2H, S355J2+N, IS 4923 / ASTM A500 / As Per Requirement
Sizes : 300 mm NB
Wall Thickness : 1.8mm to 14.27mm
Length : 6000 to 12000/18000mm
Type : Seamless/ Welded / ERW
Dimensional Tolerances : Thickness : (All sizes +/- 10%)
Packing : In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection : Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
Nominal Bore | Outside diameter | Thickness | Weight |
mm | mm | mm | kg/m |
15 | 21.3 | 2.00 | 0.95 |
2.60 | 1.21 | ||
3.20 | 1.44 | ||
20 | 26.9 | 2.30 | 1.38 |
2.60 | 1.56 | ||
3.20 | 1.87 | ||
25 | 33.7 | 2.60 | 1.98 |
3.20 | 0.24 | ||
4.00 | 2.93 | ||
32 | 42.4 | 2.60 | 2.54 |
3.20 | 3.01 | ||
4.00 | 3.79 | ||
40 | 48.3 | 2.90 | 3.23 |
3.20 | 3.56 | ||
4.00 | 4.37 | ||
50 | 60.3 | 2.90 | 4.08 |
3.60 | 5.03 | ||
5.00 | 6.19 | ||
65 | 76.1 | 3.20 | 5.71 |
3.60 | 6.42 | ||
4.50 | 7.93 | ||
80 | 88.9 | 3.20 | 6.72 |
4.00 | 8.36 | ||
4.80 | 9.90 | ||
100 | 114.3 | 3.60 | 9.75 |
4.50 | 12.20 | ||
5.40 | 14.50 | ||
125 | 139.7 | 4.50 | 15.00 |
4.80 | 15.90 | ||
5.40 | 17.90 | ||
150 | 165.1 | 4.50 | 17.80 |
4.80 | 18.90 | ||
5.40 | 21.30 | ||
150 | 168.3 | 5.00 | 20.1 |
6.3 | 25.2 | ||
8.00 | 31.6 | ||
10.00 | 39 | ||
12.5 | 48 | ||
200 | 219.1 | 4.80 | 25.38 |
6.00 | 31.51 | ||
8.00 | 41.67 | ||
10.00 | 51.59 | ||
250 | 273 | 6.00 | 39.51 |
8.00 | 52.30 | ||
10.00 | 64.59 | ||
300 | 323.9 | 6.30 | 49.36 |
8.00 | 62.35 | ||
10.00 | 77.44 |
