Mahaveer Steels is a maker and supplier that arrangements steel things into Indian business areas and diverse supposed undertakings. We have a wide scope of steel grade things which are needed in step by step families and mechanical livelihoods. We have different sizes and standards in tempered steel 304/304L/304H Pipes Tubespredictable and welded pipe composite.
Tempered steel 304L steady and welded pipes are involve low carbon combination, which gives astonishing resistance from refinement during warm frameworks. This metal is furthermore impenetrable to sulfuric and other damaging acids. This grade contains a moderate proportion of molybdenum and chromium; these metals have ridiculous dangerous safe properties, which help in the fight against hurtful reactions. Tempered steel 304L is non-alluring notwithstanding can show relatively few appealing properties while welding.
304H reliable and welded pipes are created utilizing unmatched quality rough material. This grade is astoundingly used in fabricate as it's anything but's a high proportion of carbon in it. This grade is more bendable than 316 and significantly used in endeavors where chloride is constantly being used. 304H has an exceptional yield and unbending nature.
Pipe Specification : ASTM A312, A358 / ASME SA312, SA358
Dimension Standard : ANSI B36.19M, ANSI B36.10
Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Outside Finish : 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
SS 304H | 1.4948 | S30409 | SUS 304H | - | - | - | - |
All Pipes is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
Pipe/Tube | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
---|---|---|---|---|---|---|
Stainless Steel 304/304L/304H Pipes | 1/8″ |
|
|
|
||
Stainless Steel 304/304L/304H Pipes | 1/4″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 3/8″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 1/2″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 3/4″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 1″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 1 1/4″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 1 1/2″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 2″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 2 1/2″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Seamless Pipes | 3″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 4″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Seamless Pipes | 5″ |
|
|
|
|
|
Stainless Steel 304/304L/304H Pipes | 6″ |
|
|
|
|
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | - | 8 – 11 | - |
SS 304L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | - | 8 – 13 | - |
SS 304H | 0.10 max | 2 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | - | 8 – 10.5 | - |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
