Mahaveer Steel Inc is an association well known for definite and quality creation work. We supply thing exclusively subsequent to ensuring its quality. Hastelloy C4/C22/C276 Flanges is really extraordinary and totally arranged things. We have certification for making distinctive currently crucial things. The thing's that we design and make outstanding, imaginative and advancement based. We have a get-together of experienced and talented specialists they are fit in conveying any thing with the best quality.
We keep all the prosperity standards present with us. We try to keep our thing's features and characteristics inside the normal reach. We use the most suitable and quickly open unrefined material for the creation reason. We test it for various limits and features. Hastelloy C4/C22/C276 Flanges by Mahaveer Steel Inc suggests a first class quality thing quickly available in the market at moderate esteeming.
We think and work for our significant customers and try to organize with their requirements with our commitments. Our caused things to work on utilitarian working and make the business advantageous. In like manner, we use the latest creation device and testing workplaces to help its accommodation. We have acquired all out shopper unwaveringness through Hastelloy C4/C22/C276 Flanges.
Our Hastelloy C4/C22/C276 Flanges are perceived for the most part due to its incredible and against damaging properties. The association is filling in as the eminent maker and specialist of Hastelloy C4/C22/C276 Flanges. We use the high-grade rough material to convey the best thing. We take the rough material from our solid suppliers. We scatter our things to various customers present in the country. We fitting our things to various customers present in the country.
Specification : ASTM B564 / ASME SB564
Dimension Standard : ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44
Standard : STM / ASME SB 564 / 160 / 472.
Size : : ½” NB to 12” NB
Class / Pressure : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS , ASA 150#, ASA 300# DIN ND 6,10,16,25,40 Etc
| STANDARD | UNS | WNR. | EN | JIS | OR | GOST |
| Hastelloy C22 | N06022 | 2.4602 | NiCr21Mo14W | NW 6022 | - | - |
| Hastelloy C276 | N10276 | 2.4819 | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
All Flanges is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Standard | Class | Diameter | Bolt Circle Diameter | Number of Bolts | Bolt Size | Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C22 | 50.015 | 0.010 max | 12.50-14.50 | 0.50 max | 0.08 max | 2.00-6.00 | 0.02 max | 0.02 max | 2.50 max | 20.00-22.50 | - | - |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45,000 , MPa – 310 | 45 % |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
